3 burner 8mm temperred glass cost iron pan support gas stove |
Gas stove general features |
1.panel:8mm tempered glass
2.iron pan supporter
3.SABAF burner,heat power3.2 &2.65 &1.75 &1.0.
4.caps:dull polish
5.button:mental round button
6.back shell:cold spray
7.valve:regulator
8. Safety device can be optional
9.ignition:Auto battery ignition/electric ignition
10.High efficience,save time,save gas,save money
11.Special adjust board with fixed gear,burning more steadily
Gas stove Dismension | |
Body Size | 600*520*125mm |
Packing Size | 630*550*165mm |
Cave Size | 550*470*R25 |
Burner Size | Big:100mm middle:95mm Small:65mm |
Gas stove description |
Aluminum-alloyed burners sabaf burner for all of doublemax gas cooker.
The main flame from the double rings high power five spouts air injection system will convert from the outer ring to the center, it will enhance the main flame to focus more precisely on the key positions of cooking by improving the heat efficiency and ensure balanced heat energy and save more energy.
.
Gas stove description |
1)Automatic fire valve with the CE certificate.
2)The valve with the Micro-Switch more safety.
3)Copper and aluminum valve.
Gas stove description |
1)Pulse ignition, 100% ignition and rapid ignite.
2)successful ignition in the condition of pressure instability.
3)Pulse igniter have high-quality products and competitive price.
4)Igniter have passed the CSA and CE.
Burner and Nozzle Specifications |
Burner and nozzle specifications | ||||||
Liquid gas | Natural gas | |||||
Burner | Thermal power (kw) | Nozzle 1/100(mm) | Flow (g/h) | Thermal power (kw) | Nozzle 1/100(mm) | Flow (g/h) |
Triple ring burner | 3.2 | 92 | 232 | 3.2 | 135 | 326 |
Rapid burner | 2.8 | 77 | 203 | 2.8 | 121 | 262 |
Semi rapid burner | 1.75 | 65 | 127 | 1.75 | 90 | 166 |
Auxiliary burner | 1 | 50 | 73 | 1 | 77 | 95 |
Supply pressures (Nomimal(mabr) | 28-30 | 20 | ||||
Maximum(mabr) | 35 | 25 | ||||
Minimum(mabr) | 20 | 15 |
Gas stove quality control |
1)Our products gas water heater have achieved CE approval
2)Every product gas water heater will be tested in the factory line before packed
3)Sample of gas water heater can be offered for you inspection
4)Carton packaging, built-in batten, ensure products in good transportation to your port
Gas stove certificate |
Gas water heater have CE certificate,SASO,COC,CCC,CB,can be optional.
Gas stove Packing& Shipping |
1.All of Haodi gas hobs packed by 5 layers export standarded cartons.
2.The burner caps all fixed by the stickers.
3.The Pan supporters all fixed into the foam, the foam can stand a human.
4.Sample of gas stove can be prepared in 1 week
5.20'GP/40'HQ goods can able to prepared in 25days
Load Quantity | ||
20GP | 40GP | 40HQ |
489pcs | 1014pcs | 1189pcs |
Our service |
1.1 year warranty
2.1%-2%Spare Parts
3.OEM & ODM are welcome
4.CkD anfd SKD are available.
5.tried orders are available
6.sample of gas water heater can be supplied in 7days
